APOLLOLIFT  |  SKU: A-3049

Full Electric Straddle Stacker A-3049

$5,700.00 $6,300.00
  • Capacity: 3300 lbs.
  • Max.Lifting Height: 130"
  • Battery Spec: 24V/100AH
  • Support Legs: Straddle
Powered by Affirm
Summer Sale: 3% OFF!
Apply code at checkout

Replacement Parts

30-Day Returns
1-Year Warranty
Full-Set Forklift Parts

For Taller Racks & Real Pallet Work

Built for the warehouse grind: higher stacking when you need it, strong pallet handling when it counts, and easy maneuvering for aisles + staging—so daily moves feel simple, not stressful.

Step-up height for taller racks: The upgrade when 118" is just not enough (max lift height 130").

Heavy capacity for real loads: Built for demanding pallets (capacity 3300 lbs).

GEL battery preference covered: A practical choice for customers who prefer GEL (battery type Gel, battery spec 24V/100Ah).

Straddle design for pallet compatibility: Closed-deck-safe default for mixed pallets (support leg type Straddle).

Aisle-friendly footprint: Works in standard lanes and staging zones (aisle width 87.8").

Clearance check made easy: Helps you confirm fit before buying (mast lowered height 90.4").

Specifications

  • Capacity
    3300 lbs.
  • Aisle Width
    87.8"
  • Max.Lifting Height
    130"
  • Inside Distance Between Forks
    0.1-23.6"
  • Fork Length
    42"
  • Fork Overall Width
    7.9-31.5"
  • Single Fork Width
    3.9"
  • Compatible Pallet Types
    All
  • Overall Height
    90.4-157.3"
  • Overall Length
    68.9"
  • Overall Width
    45.9-61.6"
  • Driving Speed-Unladen
    3.1 mph
  • Driving Speed-Laden
    2.8 mph
  • Lifting Speed/Empty
    5.9 inch/s
  • Lifting Speed/Loaded
    3.5 inch/s
  • Gradeability/Empty
    15%
  • Gradeability/Loaded
    6%
  • Support Leg Type
    Straddle
  • Total Wheel Count
    3
  • Turning Radius
    53"
  • Mast Lowered Height
    90.4"
  • Mast Extended Height
    157.3"
  • Load Centre Distance
    23.6"
  • Battery Capacity
    105AH
  • Battery Spec
    24V/105AH
  • Battery Voltage
    24V
  • Battery Type
    Gel Battery
  • Fork Thickness
    1.4"
  • Fork Lowered Height
    2.8"
  • Lowering Speed/Empty
    4.3 inch/s
  • Lowering Speed/Loaded
    5.9 inch/s
  • Service Weight
    1450 lbs.
  • Gross Weight
    1490 lbs.
  • Charger
    24V/10A built-in
  • Charging Time
    8-10 Hours
  • Package Size
    44"x34"x93"

Full Electric Stacker

High-Efficiency Solution for Daily Stacking Operations

Full electric stackers feature powered lift and powered travel, designed for consistent stacking and material handling.

  • Increased productivity
  • Reduced operator fatigue
  • Lower cost and maintenance compared to forklifts
  • Ideal for narrow aisle environments
Best Fit
Medium to large warehouses with regular stacking requirements.
Positioning:
A cost-effective alternative to traditional forklifts for many indoor warehouse applications.

⚠️ Notice:

  • Support legs require installation before use. Installation Video: https://www.youtube.com/watch?v=-qGQwzVQdYAWI
  • For optimal battery longevity and reliable performance, we recommend charging battery-equipped products monthly (even during storage).

Links

Product brochure

Product comparison
Full Electric Straddle Stacker A-3049
$5,700.00 $6,300.00
Full Electric Straddle Stacker A-3047
$5,500.00 $6,100.00
Capacity (lb)
Capacity (lb)
3300 lbs.
3300 lbs.
Max Lifting Height (in)
Max Lifting Height (in)
130"
118"
Max Fork Height (in)
Max Fork Height (in)
2.8"
2.8"
Service Weight (lb)
Service Weight (lb)
1450 lbs.
1408 lbs.
Fork Size (in)
Fork Size (in)
42" x 7.9-31.5"
42" x 7.9-31.5"
Lowered Mast Height (in)
Lowered Mast Height (in)
90.4"
84.4"
Turning Radius (in)
Turning Radius (in)
53"
53"
Aisle Width (in)
Aisle Width (in)
87.8"
87.8"
Leg Type
Leg Type
Straddle
Straddle
Compatible Pallets
Compatible Pallets
All
All
Adjustable Forks
Adjustable Forks
Yes
Yes
Charger
Charger
24V/10A built-in
24V/10A built-in
Mast Stages
Mast Stages
2 Stage
2 Stage
Fork Length (in)
Fork Length (in)
42"
42"
Fork Overall Width (in)
Fork Overall Width (in)
7.9-31.5"
7.9-31.5"
Single Fork Width (in)
Single Fork Width (in)
3.9"
3.9"
Fork Thickness (in)
Fork Thickness (in)
1.4"
1.4"
Fork Lowered Height (in)
Fork Lowered Height (in)
2.8"
2.8"
Inside Distance Between Forks (in)
Inside Distance Between Forks (in)
0.1-23.6"
0.1-23.6"
Overall Length (in)
Overall Length (in)
68.9"
68.9"
Overall Width (in)
Overall Width (in)
45.9-61.6"
45.9-61.6"
Overall Height (in)
Overall Height (in)
90.4-157.3"
84.4-143.5"
Driving Speed - Unladen (mph)
Driving Speed - Unladen (mph)
3.1 mph
3.1 mph
Driving Speed - Laden (mph)
Driving Speed - Laden (mph)
2.8 mph
2.8 mph
Lift Speed - Unladen
Lift Speed - Unladen
5.9 inch/s
5.9 inch/s
Lift Speed - Laden
Lift Speed - Laden
3.5 inch/s
3.5 inch/s
Turtle Speed Mode
Turtle Speed Mode
Yes
Yes
Gradeability (Empty)
Gradeability (Empty)
15%
15%
Gradeability (Loaded)
Gradeability (Loaded)
6%
6%

Frequently Asked Questions

How to calculate shipping fee?

At checkout, shipping fees will automatically be calculated based on your delivery address and the items in your order. Standard shipping rates apply to commercial addresses and do not include additional services such as inside delivery. Additional fees may apply for additional services or delivery to remote locations.If you are ordering multiple items, please contact info@apolloliftus.com, as we may be able to offer a shipping discount.

When will I receive my order?

Your order will typically be shipped from our warehouse within 48 business hours. Once shipped, the estimated transit time is 3–5 business days. Actual delivery time may vary depending on the carrier’s schedule, and our logistics team will monitor the process throughout. For pre-sale items, please refer to the estimated delivery time shown on the product page.

How can I get my invoice?

Please email us with your PO number at info@apolloliftus.com. Our team will process and send you the invoice

Can I pick up my order?

Yes. You need to select "Pick Up" for delivery method. After order confirmation, our team will email the pick up slip to you. Please make sure to check your email inbox. Please make sure to bring a copy of your pickup slip and arrive at the designated time and address indicated on the slip. Pickup hours are Monday through Friday, from 9:00 AM to 4:00 PM, excluding public holidays.

Can I purchase spare parts or batteries separately?

Yes. You can purchase the spare parts on our website. If you are not sure what parts you need or cannot find the parts you need, please contact our service team service@apolloliftus.com with products' photos, parts name or phots and SKU for help.

Do Electric Products come with accessories?

Yes, our electric products include an original charger and battery set, and it is recommended to charge them immediately upon receipt.

What is the difference between lead-acid batteries and lithium batteries?

Lead-acid batteries: mature technology, stable performance in high and low temperatures, require longer charging times and longer work time.Lithium batteries: lightweight, compact, charge quickly, require no maintenance, and are environmentally friendly, making them more suitable for high-frequency usage.

What is the difference between the fixed legs and the cross legs of a forklift?

Fixed legs are only suitable for pallets with bottom openings; Straddle legs models are suitable for all standard pallets (the pallet size must be smaller than the straddle leg spacing), and some models have adjustable straddle legs spacing.
