1 3
6600 lbs.
6600 lbs.
Capacity
48" x 27"
48" x 27"
Fork Size
155 lbs.
155 lbs.
Service weight
52.5"
52.5"
Turning Radius
APOLLOLIFT  |  SKU: A-1005

Hand Pallet Truck A-1005

$250.00
  • Capacity: 6600 lbs.
  • Fork Size: 48" x 27"
  • Wheels: PU
Powered by Affirm
Summer Sale: 3% OFF!
Apply code at checkout
30-Day Returns
1-Year Warranty
Full-Set Forklift Parts

Standard type pallet truck for heavy-duty warehouse use: Built to handle 6600 lb loads for routine pallet movement. Service weight 155 lbs, gross weight 160 lbs.

Chrome piston and ram for smooth operation: Reduces wear on pump and seals for long-lasting, reliable lifting.

Efficient 10-stroke lift system: Lift height per stroke 11 mm, allowing controlled raising with fewer strokes.

Forks designed for standard pallets: 27" overall fork width, fork length 48", single fork width 5.9", inside distance 15".

Maneuverable in tight warehouse aisles: Excellent 180° turning angle for smooth handling. Turning radius 52.5", aisle width 70.4", max lift height 7.5", fork lowered height 3".

Specifications

  • Capacity
    6600 lbs.
  • Aisle Width
    70.4"
  • Max.Lifting Height
    7.5"
  • Inside Distance Between Forks
    15"
  • Fork Length
    48"
  • Fork Overall Width
    27"
  • Single Fork Width
    5.9"
  • Compatible Pallet Types
    All
  • Overall Height
    46.3"
  • Overall Length
    62.5"
  • Overall Width
    27"
  • Load Wheel Type
    Single Wheel
  • Total Wheel Count
    4
  • Turning Radius
    52.5"
  • Lifting Distance
    4.5"
  • Fork Thickness
    2.1"
  • Control Handle Foldability
    NO
  • Fork Lowered Height
    3"
  • Service Weight
    155 lbs.
  • Gross Weight
    160 lbs.
  • Package Size
    63"x28"x18"

Manual Pallet Jack

Entry-Level Solution for Light-Duty Handling

Manual pallet jacks are designed for low-frequency, short-distance pallet movement. They are the most economical option for basic ground-level transport.

  • Ideal for occasional use
  • Simple, durable, and low maintenance
  • No power source required
  • Best suited for tight spaces and light workloads
Best Fit
Retail stockrooms, small backrooms, delivery unloading, or as backup equipment.
When to Upgrade:
If daily movement becomes frequent or operator fatigue becomes a concern, an Electric Pallet Jack is recommended.

⚠️ Notice:

  • Handle Self-Installation Required

Processing Time Update

  • Processing Time: This product requires at least 5 business days to process before shipping.

Product Comparison
Hand Pallet Truck A-1003
$200.00
Hand Pallet Truck A-1004
$210.00
Hand Pallet Truck A-1005
$250.00
Capacity (lb)
Capacity (lb)
5500 lbs.
5500 lbs.
6600 lbs.
Max Lifting Height (in)
Max Lifting Height (in)
7.5"
7.5"
7.5"
Max Fork Height (in)
Max Fork Height (in)
3"
3"
3"
Service Weight (lb)
Service Weight (lb)
132 lbs.
138 lbs.
155 lbs.
Fork Size (in)
Fork Size (in)
48" x 21"
48" x 27"
48" x 27"
Turning Radius (in)
Turning Radius (in)
52.5"
52.5"
52.5"
Aisle Width (in)
Aisle Width (in)
70.4"
70.4"
70.4"
Compatible Pallets
Compatible Pallets
All
All
All
Fork Length (in)
Fork Length (in)
48"
48"
48"
Fork Overall Width (in)
Fork Overall Width (in)
21"
27"
27"
Single Fork Width (in)
Single Fork Width (in)
5.9"
5.9"
5.9"
Fork Thickness (in)
Fork Thickness (in)
2.1"
2.1"
2.1"
Fork Lowered Height (in)
Fork Lowered Height (in)
3"
3"
3"
Inside Distance Between Forks (in)
Inside Distance Between Forks (in)
8.7"
15"
15"
Wheel Type
Wheel Type
Single Wheel
Single Wheel
Single Wheel
Overall Length (in)
Overall Length (in)
62.5"
62.5"
62.5"
Overall Width (in)
Overall Width (in)
21"
27"
27"
Overall Height (in)
Overall Height (in)
46.3"
46.3"
46.3"

Frequently Asked Questions

How to calculate shipping fee?

At checkout, shipping fees will automatically be calculated based on your delivery address and the items in your order. Standard shipping rates apply to commercial addresses and do not include additional services such as inside delivery. Additional fees may apply for additional services or delivery to remote locations.If you are ordering multiple items, please contact info@apolloliftus.com, as we may be able to offer a shipping discount.

When will I receive my order?

Your order will typically be shipped from our warehouse within 48 business hours. Once shipped, the estimated transit time is 3–5 business days. Actual delivery time may vary depending on the carrier’s schedule, and our logistics team will monitor the process throughout. For pre-sale items, please refer to the estimated delivery time shown on the product page.

How can I get my invoice?

Please email us with your PO number at info@apolloliftus.com. Our team will process and send you the invoice

Can I pick up my order?

Yes. You need to select "Pick Up" for delivery method. After order confirmation, our team will email the pick up slip to you. Please make sure to check your email inbox. Please make sure to bring a copy of your pickup slip and arrive at the designated time and address indicated on the slip. Pickup hours are Monday through Friday, from 9:00 AM to 4:00 PM, excluding public holidays.
